Limitations of use

• Do not use it for respiratory protection against unknown atmospheric contaminants or when concentrations of contaminants are unknown or immediately dangerous to life or health (IDLH).
• Do not use it in atmospheres containing less than 19.5% oxygen. (3M definition. Individual countries may apply their own limits on oxygen deficiency. Seek advice if in doubt).
• Do not use it against contaminants with poor warning properties.
• The filter cannot be cleaned and should be replaced if excessively dirty.
• Keep the inner filter seal clean. The seal can be cleaned with fresh water but ensure that water does not enter the filter.
• Never attempt to clean filters by knocking or blowing out accumulated material.

Service Life

The lifespan of these filters depends on several factors, including duration of use, the selected airflow rate, and the concentration of airborne particulates in the environment. The air filter unit is equipped with both visual and audible alarms to monitor the filter’s condition.

An indicator on the control panel shows the current status of the particle filter, and a warning alarm will activate when the filter reaches capacity. At this point, the filter must be replaced with a new one to maintain effective respiratory protection.

Storage Instructions

• Store in the original packaging in a dry and clean environment.
• Keep away from direct sunlight, high temperatures, petrol, and solvent vapours.
• Do not store outside the temperature range of -30ºC to +50ºC or in humidity levels above 90%.
• For extended storage, maintain a temperature range of 4ºC to 38ºC.

Always verify that the product is within its stated shelf life or use-by date prior to initial use. Proper storage ensures the product remains effective and ready for use when needed.

Typical Properties

Brand: 3M™

Cartridge or Filter Type: Particulate & Nuisance Organic Vapor

Case Quantity: Single / 5

Intrinsically Safe: No

Product Series: TR-300+

Product Type: Filter & Pre-filter

Protection Type: Respiratory Protection

Purpose: PAPR

Respirator Compatibility: TR-300+ Series

Spare Part Type: Filters & Cartridges

Specifications Met: AS/NZS 1716

Dimensions

Overall Height (Metric): 0.13m

Overall Length (Metric): 0.35m

Overall Width (Metric): 0.2m
